Product Detail
CXI-2UM2
2U Industrial Chassis
.jpg)
.jpg)
.jpg)
- Item Number: CXI-2UM2
- Product Category: 2U
2U Rack mount server chassis
- ATX M/B with 4 driver bays
- PCIe and PCI Riser card
- Supports 2U 500W single or 2U 380W redundant PSU
Full Description
| Construction | Heavy-duty steel with Ni plating |
| Color | Black |
| Board support | ATX motherboard |
| Drive bays | 1 x 5.25" & 1 x 3.5" ext. Drive bays, 2 x 3.5" internal Drive bays |
| Expansion |
Option 1: (3) 32-bit PCI slots, Option 2: (1) 32-bit PCI, (1) PCIe x 16, (1) PCIe x 1 slots Option 3: (2) 32-bit PCI and (1) PCIe x 16 slots |
|
Power supply |
Up to 500W 2U single or up to 380W 2U redundant PSU |
| Cooling system |
2 x 80mm ball-bearing fans with replaceable air filter |
| I/O port | 1 x PS/2 connector, 2 x USB 2.0, Power on/off and reset switch |
| Indicator | Power on/off and HDD activity LEDS |
| Operating Temperature |
0°~55°C |
| Gross weight | 9.4 kg |
| Dimension (WxHxD)(mm) | 434 x 450 x 88 |
